Intel MAX® V CPLDs

MAX® V CPLDs offer a unique, non-volatile architecture, delivering low power and on-chip features, suitable for Intel Edge-Centric applications.

Intel MAX® V CPLDs Benefits:

Best CPLD Value

When you use MAX® V devices, you'll enjoy lower total system cost because the MAX® V architecture integrates previously external functions, such as flash, RAM, and oscillators. MAX® V CPLDs deliver a large number of I/Os and logic per footprint. The devices also use low-cost and green packaging technology, with packages as small as 20 mm.

Lower Total Power

• With MAX® V CPLDs, you'll get robust new features at up to 50 percent lower total power vs. other equivalent-density CPLDs on the market.
• Extended battery life with static power as low as 45 uW.
• As few as one power supply (Vcc-core) required, which also lowers bill of materials (BOM) costs.

Built on a mature and low-cost wafer fab process, MAX® V CPLDs leverage a proven architecture while delivering robust features including:

• In-system programming (ISP), which lets you program the device while it is in operation, so you can perform in-field updates without affecting overall system operation.
• User flash memory, embedded flash memory that provides non-volatile memory storage of critical system information.

Easy-to-Use, Free Design Software

MAX® V CPLDs are supported with free Intel® Quartus® Prime Lite Edition software. With Intel® Quartus® Prime Software, you'll get productivity enhancements resulting in faster simulation, faster board bring-up, and faster timing closure. This software also comes with a system-level integration tool called Qsys, delivering higher circuit performance while also enabling you to design at a higher level of abstraction.
